亮點：
Highlights:
1、采用雙機油缸，配有大體積膠缸，可一次性裝載14L丁基膠（2塊正常的￠180mm的丁基膠）。
1. Double machine oil cylinder is adopted and equipped with large volume rubber cylinder, which can load 14L butyl rubber (two normal ￠ 180mm butyl rubber) at one time.
2、增壓系統的主泵采用德國原裝進口麥格思維特（MAXIMATOK）的增壓泵。
2. The main pump of the booster system adopts the booster pump of maximatok imported from Germany.
主要性能特點:
Main performance features:
1、該機為半自動涂布機（即人工扶持間隔框進行逐邊操作）,變頻調速。
1. The machine is a semi-automatic coater (i.e. manually supporting the spacer to operate side by side), with variable frequency speed regulation.
2、將間隔框放在傳送帶上人工扶持框傳送帶運行，通過傳感器時，傳送壓輪及打膠閥按設定程序自動動作。
2. Place the spacer frame on the conveyor belt and manually support the conveyor belt to run. When passing through the sensor, the transmission pressure wheel and glue valve will act automatically according to the set program.

3、擺動氣缸動作、壓輪壓下，壓送鋁間隔框行進，當間隔框到達打膠頭時打膠，將膠均勻地涂在鋁間隔框上。
3. Swing the air cylinder and press down the pressure wheel to press the aluminum spacer frame. When the spacer frame reaches the gluing head, apply the glue evenly on the aluminum spacer frame.
4、等間隔框另一側快要到達壓輪時，壓輪抬起，離開打膠頭時，膠閥自動關閉，停止打膠，以上程序由PC控制，時間有人機界面控制，可以觸摸調節。
4. When the other side of the equal interval frame is about to reach the pressing wheel, the pressing wheel will lift up. When leaving the gluing head, the glue valve will automatically close and stop gluing. The above program is controlled by PC, and the time is controlled by man-machine interface, which can be adjusted by touch.
5、在設計、選用元氣件以及涂膠效果方面，在國內均屬水平。
5. In terms of design, selection of vitality parts and gluing effect, it is at the domestic level.
6、采用PC控制系統，定位、傳送、涂膠均自動完成。
6. Using PC control system, positioning, transmission and gluing are completed automatically.
7、輸送采用變頻調速電機調速，運行速度平穩。
7. The transmission adopts frequency conversion speed regulation motor speed regulation, and the running speed is stable.
8、有不泄壓即可自動調定位機構，充分保證涂膠膠頭與隔框兩側間距涂膠均勻。
8. The positioning mechanism can be adjusted automatically without pressure relief to fully ensure the uniform spacing between the gluing head and both sides of the spacer frame.
以上就是為大家介紹的有關全自動丁基膠涂布機的詳細介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://m.txxfj.com
The above is a detailed introduction to the full-automatic butyl adhesive coater. I hope it will be helpful to you If you have any questions, please contact us We will provide you with professional service http://m.txxfj.com
